Name of machine: FBV-50Y die cut bottle shape bag fruit juice packaging machine
Irregular shape pouch packing machine can date printing, bag forming, filling, sealing, cutting, finished product output, etc.
VFFS shape bag juice packaging machine can be use to package fruit jam, juice, beverage, honey, cosmetic liquid, shampoo, shower gel, and other productds.
Fully automatic SHFB-50Y irregular shape bag liquid packing machine is mainly composed of film rolling device, date printing, liquid pump device, bag former, vertical and horizontal sealing device, shape cutting device, finished product output and other devices. The entire irregular shape pouch packing machine is controlled by a PLC ystem to control the bag making speed or size, which is convenient for viewing and adjusting packing parameters.
Special-shaped bag liquid packaging machine is made of stainless steel, which is sturdy and durable, with a clear overall structure and easy to clean.
VFFS shape pouch packing machine can be divided into single-row machine and double-row machine, and the appropriate model can be selected according to customer needs.
Bag Former: Choose the right bag maker according to the different bags. Customize the size of the bag maker accordiing to the size of the bag to ensure accurate bag sealing.
Film Input Device: Device is installed on the back of the machine to facilitate workers to change the film roll. Film pulling and bag making are smooth and convenient for packaging.
Sealing Device: Sealing device for sealing bags on 4 sides, double sealing. Ensure the tightness of the bag and the neatness of the seal.
Shape Cutter: Customize the appropriate film cutter according to the customer's bag making requirements. The bag making cut is neat and efficient.
SHFB-50Y shape bag packing machines can be used to package liquid or paste products in the food industry, cosmetics industry, daily necessities industry or chemical industry. Suitable liquid/paste metering and feeding devices can be customized according to the characteristics of the packaged products. Irregular shape pouch packing machine is suitable for packaging liquid product, such as juice, enzyme beverage, coconut water, vinegar, cosmetic liquid, etc.
Bags that can be made by this VFFS packaging machine include irregular shape bags, stick bags, flat cut bags, 3/4 sides seal bags, etc. Suitable bag-making materials can be used according to the characteristics of the materials, such as composite film, printed films, PE films, OPP/CPP films and other different bag-making materials.
| TYPE | FVB-50Y Irregular shape sachet packing machine | FBV-50YD Irregular shape sachet packing machine |
| MACHINE SPEED | 25-30 per minute | 50-60 per minute |
| VOLUME TO FILL | (1-70 mls can be customized) | (1-50 mls can be customized) |
| POUCH SIZE RANGE | Customized Max width: 130mm, Max length: 180mm | Customized Max width: 90mm, Max length: 180mm |
| MAX, FILM WIDTH | 320mm | 420mm |
| FILM MATERIAL | Composite film/aluminum foil/paper-PE film/laminated paper | |
| BAG TYPE | Irregular Shape Pouch | |
| VOLTAGE | AC200V/50HZ Single-phase (customized) | |
| TOTAL POWER | 3KW | 4.4KW |
| MACHINE MATERIAL | Stainless Steel 304 (SS304) | |
| MACHINE SIZE | (L)1150mm*(W)1250mm*(H)2150mm | (L)1350mm*(W)1450mm*(H)2150mm |
| N.W. | 450kg | 600kg |
Our products are follow GMP requirements
We providing one-station purchase service
Our products exported to more than 40 countires from all over the world
We providing OEM service , testing and products designing for our customers
