Name of machine: Multi heads french fries bag packing machine and box packing machine
It is suit for packing french fries, jelly sahcets, potato chips, biscuits, puffed foods, etc.
Function of machine: form fill seal, date printer, multi heads weight, film input, vibrating slope conveying equipment, etc.
Materials: SS304
100% brant new, made in China
Composition of automatic french fries packaging line: vibrating slope conveying equipment+multi heads weight granular packing machine+finished tunnel metal detection+product conveying+heat shrink bag machine+cartoning machine.
FBV-420 multi heads weight granular packaging machine including functions, main packing machine, vibrating slope conveying equipment, multi-head weight, film input device, date printer, sealing and cutting device, finished product conveyor, machines are controlled by PLC system.
VFFS granules packing machins are made of SS304, we provide OEMservice and oversea service.
Vertical multi-head weight packaging machine can be used to pack various irregular granular products, such as french fries, potato chips, popcorn, peanuts, candies, biscuits, coffee beans, nuts, dried fruits, chocolates, small hardware, pistachios, etc. Granular products that can be packaged sre irregular in shape or fragile. Multi-head weigher weigher can measure more accurately and pack more efficiently. It ensures that the materials are not fragile and the products can be packaged more completely.
FBV-420 VFFS french fries bag packing machine can be customized to make veries of bags aselow: pillow bags, gusset bags, stand up bags, bags with punched hole.
According to the characteristics of the packaging particles, suitable bag making materials can be selected, such as PE, OPP, PVC, OPP/PP, OPP/PE, PET/VMPET/PE, paper polyethylene, nylon/polythylene and other composite materials.
| Model. No | FBV-420 | FBV-520 | FBV-620 | FBV-820 |
| Bag size | (L)60-230mm*(W)60-200mm | (L)100-300mm*(W)80-250mm | (L)100-380mm*(W)100-300mm | (L)50-380mm*(W)110-400mm |
| Bag speed | 15-60 bags/min | 15-60 bags/min | 15-60 bags/min | 10-30 bags/min |
| Film width | 140-420mm | 180-520mm | 220-620mm | 340-800mm |
| Air consumption | 0.6Mps 0.36m³/min | 0.6M 0.36m³/min | 0.6Mps 0.4m³/min | 0.6Mps 0.7m³/min |
| Power supply | 2.2kw,220V 50/60hz | 3kw 220V 50/60hz | 4kw 220V 50/60hz | 4.5kw 220V 50/60hz |
| Packed dimension | (L)1430*(W)970*(H)1600mm | (L)1550*(W)1160*(H)1480mm | (L)1600*(W)1260*(H)1680mm | (L)1600*(W)1500*(H)2050mm |
